Design

Colour name

Thunder Black

Product type

Mobile workstation

Product colour

Black

Form factor

Clamshell

Housing material

Polycarbonate (PC), Acrylonitrile butadiene styrene (ABS)

Display

Display diagonal

40.6 cm (16")

Display resolution

1920 x 1200 pixels

Touchscreen

No

HD type

WUXGA

Panel type

IPS

LED backlight

Yes

Native aspect ratio

16:10

Anti-glare screen

Yes

Display brightness

300 cd/m²

RGB colour space

NTSC

Colour gamut

45%

Contrast ratio (typical)

800:1

Processor

Processor manufacturer

AMD

Processor family

AMD Ryzen™ 9 PRO

Processor model

7940HS

Processor frequency

4 GHz

Processor boost frequency

5.2 GHz

Processor cores

8

Processor cache

16 MB

Processor cache type

L3

Motherboard chipset

AMD SoC

Memory

Internal memory

32 GB

Internal memory type

DDR5-SDRAM

Memory clock speed

5600 MHz

Memory form factor

SO-DIMM

Memory layout (slots x size)

1 x 32 GB

Memory slots

2x SO-DIMM

Maximum internal memory

64 GB

Memory channels

Dual-channel

Non-ECC

Yes

Storage

Total storage capacity

1 TB

Storage media

SSD

Total SSDs capacity

1 TB

Number of SSDs installed

1

SSD capacity

1 TB

SSD memory type

TLC

SSD interface

PCI Express 4.0

NVMe

Yes

SSD form factor

M.2

Optical drive type

No

Card reader integrated

Yes

Compatible memory cards

SD

Graphics

Discrete GPU manufacturer

NVIDIA

Discrete graphics card model

NVIDIA RTX 2000

On-board graphics card

Yes

Discrete graphics card

Yes

On-board graphics card model

AMD Radeon 780M

Discrete graphics card memory

8 GB

Discrete graphics memory type

GDDR6

Audio

Audio chip

Realtek ALC3287

Audio system

Dolby Audio Premium

Number of built-in speakers

2

Speaker power

2 W

Built-in microphone

Yes

Number of microphones

2

Camera

Front camera

Yes

Front camera resolution (numeric)

5 MP

Infrared (IR) camera

Yes

Privacy camera

Yes

Privacy type

Privacy shutter

Network

Top Wi-Fi standard

Wi-Fi 6E (802.11ax)

Wi-Fi standards

Wi-Fi 6E (802.11ax)

Mobile network connection

No

Antenna type

2x2

WLAN controller model

Qualcomm NFA725A

WLAN controller manufacturer

Qualcomm

Ethernet LAN

No

Bluetooth

Yes

Bluetooth version

5.1

WWAN

Upgradable

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

USB4 Gen 3x2 ports quantity

2

HDMI ports quantity

1

HDMI version

2.1

Combo headphone/mic port

Yes

USB Type-C DisplayPort Alternate Mode

Yes

USB Power Delivery

Yes

USB Sleep-and-Charge

Yes

USB Sleep-and-Charge ports

1

Keyboard

Pointing device

ThinkPad UltraNav

Keyboard layout

AZERTY

Keyboard language

Belgian

Numeric keypad

Yes

Keyboard backlit

Yes

Spill-resistant keyboard

Yes

Software

Operating system language

German, Dutch, English, French, Italian

Operating system installed

Windows 11 Pro

Battery

Battery technology

Lithium Polymer (LiPo)

Battery capacity

90 Wh

Fast charging

Yes

Power

AC adapter power

170 W

AC adapter frequency

50 - 60 Hz

AC adapter input voltage

100 - 240 V

Security

Cable lock slot

Yes

Cable lock slot type

Kensington

Fingerprint reader

Yes

Smart card reader

No

Trusted Platform Module (TPM)

Yes

Trusted Platform Module (TPM) version

2.0

Password protection

Yes

Password protection type

Power on, Supervisor, SSD

Operational conditions

Operating temperature (T-T)

5 - 35 °C

Storage temperature (T-T)

5 - 43 °C

Operating relative humidity (H-H)

8 - 95%

Storage relative humidity (H-H)

5 - 95%

Maximum shipping altitude

3048 m

Certificates

Certification

MIL-STD-810H

Sustainability

Sustainability certificates

RoHS, TCO

Weight & dimensions

Width

365 mm

Depth

262 mm

Height

24.7 mm

Weight

2.2 kg
