Performance

Type

IP security camera

Placement supported

Outdoor

Connectivity technology

Wired

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Dynamic range

120 dB

Design

Form factor

Turret

Mounting type

Ceiling/wall

Product colour

White

Housing material

Metal, Plastic

International Protection (IP) code

IP67

Camera

Minimum illumination

0.005 lx

Lens viewing angle, horizontal

100°

Lens viewing angle, vertical

54°

Lens viewing angle, diagonal

118°

Tilt angle range

0 - 85°

Pan range

0 - 360°

Camera shutter speed

1/3 - 1/10000 s

Number of Privacy masking areas

4

Image sensor

Optical sensor size

25.4 / 2.7 mm (1 / 2.7")

Progressive scan

Yes

Sensor type

CMOS

Lens system

Number of lenses

1

Detect distance

64 m

Observe distance

27 m

Recognize distance

13 m

Maximum aperture number

1.6

Identify distance

6 m

Minimum aperture number

1.6

Focal length range

2.8 mm

Fixed focal length

2.8 mm

Night vision

Night vision

Yes

Night vision distance

30 m

LED type

IR

Number of illumination LEDs

4

Video

Maximum resolution

2988 x 1520 pixels

Total megapixels

4 MP

Video compression formats

H.264, H.264+, H.265, H.265+

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2550 x 1440, 2688 x 1520

Frame rate

60 fps

Noise reduction

Yes

Noise reduction technology

3D noise reduction

Audio

Built-in speaker(s)

Yes

Sample rate

8 kHz

Signal-to-Noise Ratio (SNR)

52 dB

Built-in microphone

Yes

Bit rate range

64 - 64 Kbit/s

Network

Ethernet LAN

Yes

Supported network protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

Security

Password protection

Yes

IP address filtering

Yes

Privacy protection

Yes

Digest authentication

Yes

Power

Power source type

DC

Power consumption (max)

10.1 W

Operational conditions

Operating temperature (T-T)

-30 - 60 °C

Storage temperature (T-T)

-40 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage relative humidity (H-H)

0 - 95%

Weight & dimensions

Width

111 mm

Depth

111 mm

Height

83.7 mm

Weight

480 g

Packaging content

Number of cameras

1
